ABB DPT63-CB010 C4 3Ptomatic transfer switching equipment is automatic conversion device terminal type derived from HYCQ5 series, suitable for AC 50Hz, rated voltage AC400V/230V, rated current to 63A three-phase four wire (also can be used for a phase line) dual power supply, automatic one or several load circuit from a power source. To another power, in order to ensure the normal power supply load circuit. This product is suitable for industrial, commercial, commercial and residential and other more important places.

Structure
ABB DPT63-CB010 C4 3Pautomatic switch electrical equipment is made up of small circuit breaker (DZ47-63) single operating mechanism, control circuit and so on. All the components are installed on the same board. The power supply voltage of the automatic switching device is AC230V, and the mechanical life is 5000 times.Perbance
ABB DPT63-CB010 C4 3P(dual power only can automatic recovery of power supply (two) are known as the normal power supply and reserve power supply) phase voltage (automatic power control) detection at the same time, when the power is abnormal, the miniature circuit breaker A phase of pressure loss or lack of phase, automatic switching controller device the delay to the standby power supply; when the power is recovered, the automatic controller device without delay to return to the common power supply, does not allow two power and abnormal.

DPT63-CB010 C0.5 3P 3 6 0.5
DPT63-CB010 C1 3P 3 6 1
DPT63-CB010 C2 3P 3 6 2
DPT63-CB010 C3 3P 3 6 3
DPT63-CB010 C4 3P 3 6 4
DPT63-CB010 C6 3P 3 6 6
DPT63-CB010 C10 3P 3 6 10
DPT63-CB010 C16 3P 3 6 16
DPT63-CB010 C20 3P 3 6 20
DPT63-CB010 C25 3P 3 6 25
DPT63-CB010 C32 3P 3 6 32
DPT63-CB010 C40 3P 3 6 40
DPT63-CB010 C50 3P 3 6 50
DPT63-CB010 C63 3P 3 6 63
